4mm Diameter 1 Flute Carbide End Mill for Plasics Acrylic PVC 42mm Flute Length DLC Coated

4mm Diameter 1 Flute Carbide End Mill for Plasics Acrylic PVC 42mm Flute Length DLC Coated
Zoom  Zoom
Our Price:  £13.00
List Price:  £19.50
Saving Of:  £6.50 (33%)
(Exc. 20% VAT)(£15.60 Inc. VAT)

Model:  EP1S-04044270DLC
Brand:  APT Carbide End Mills

Shipped Weight:  35 g

Availability:

In stock, immediate despatch

In stock, immediate despatch

APT Carbide End Mills

Carbide End Mills APT Brand


4mm Diameter 1 Flute Carbide End Mill for Plasics Acrylic PVC 42mm Flute Length DLC Coated.

Made from wear resistant Uncoated Carbide for increased tool life, can be used on Aluminium, Brass, Copper, Gold, Magnesium Alloy and other Non-ferrous Metals when a cutter dedicated for these materials is not available.

DLC Diamond Like Carbon Coating can provide up to 100% increase in tool life, Honed edge flutes with polished surface decrease cutting forces and are excellent in finishing operations. Can be used for dry cutting.

When possible choose cutter with the shortest flute length and least overhang.

Dimensions for EP1S-04044270DLC single flute milling cutter (in mm)
Cutting DiameterFlute LengthOverall LengthShank Diameter
4mm42mm70mm4mm
Speeds and Feeds for router cutter, based on a max depth of 1 x diameter with high accuracy spindle and collets with optimum stability of spindle and workpiece holding, reduce feed rate for suboptimal conditions.
When cutting more than 1 x diameter reduce feed rate. For guidance only if vibration is produced try lowering the feed rate if not successful try raising feed very slowly, if no vibration is present increased feed rate may be possible.
AcrylicAluminium AlloyHard PlasticHardwoodLaminate
RPM 18000 Feed 1600 mm/minRPM 18000 Feed 1400 mm/minRPM 18000 Feed 1200 mm/minRPM 18000 Feed 1800 mm/minRPM 18000 Feed 1800 mm/min
Particle Board MDFPhenolicSoft PlasticPlywoodSolid Surface
RPM 18000 Feed 2500 mm/minRPM 18000 Feed 2400 mm/min

RPM 18000 Feed 1500 mm/min

RPM 18000 Feed 2100 mm/minRPM 18000 Feed 1100 mm/min
