ED4S-12120100 12mm Diameter 4 Flute Carbide End Mill AlTiCrN Coated 55HRC 100mm Long

(Exc. 20% VAT)(£34.08 Inc. VAT)

Model: ED4S-12120100
Brand: APT Carbide End Mills

Shipped Weight: 180 g

Availability:

Only 14 left in stock - order soon

APT Carbide End Mills

Carbide End Mills APT Brand

ED4S-12120100 12mm Diameter 4 Flute Carbide End Mill AlTiCrN Coated 12mm Plain Shank 100mm Long 45mm Flute Length.

Suitable for materials up to 55HRC, performs well on Alloy, Mould, Tool and Die Steel, 304 Stainless, Cast Iron.

Dimensions for ED4S-12120100 (mm)

Dia	Shank Dia	Length	Flute Length
12	12	100	45

Speeds and Feeds for Side Milling for Slot Milling reduce values.

Non and Low Alloy Steel and Grey Cast Iron 35HRC	Pre Hardened Quenched, Tempered Steel and Chilled Cast Iron 45HRC	Hardened Steel and Hardened Cast Iron 55HRC	Stainless Steel
RPM 3200 Feed 390 mm/min	RPM 1300 Feed 180 mm/min	RPM 790 Feed 80 mm/min	RPM 1000 Feed 120 mm/min

Up to 45HRC - 55HRC -
