APMT 113516 UM25 Carbide Inserts for Milling PVD Coated for General Use 1.6mm Radius

APMT 113516 UM25 Carbide Inserts for Milling PVD Coated for General Use 1.6mm Radius
Zoom  Zoom
Our Price:  £2.20
List Price:  £3.30
Saving Of:  £1.10 (33%)
(Exc. 20% VAT)(£2.64 Inc. VAT)

Model:  APMT113516UM25
Brand:  Uni-tip Carbide

Shipped Weight:  5 g

Availability:

Only 70 left in stock - order soon

Only 70 left in stock - order soon

Uni-tip Carbide

Carbide Inserts with CVD & PVD Coating by Uni-tip


APMT 113516 UM25 Carbide Inserts for Milling PVD Coated Grade UM25, P25, M25, K25 with PVD TiAlN Coating.

Universal grade for general Steel, Stainless & Cast.

Extra large radius of 1.6mm

Dimensions for APMT 113516 UM25 (mm)
Cutting Edge Length Inscribed Circle or Width Thickness Hole Dia Corner Radius Side Clearance
11.0 6.35 3.5 2.7 1.6 11°
General Cutting parameters
Material Material Group Cutting Speed VC: m/min Depth of Cut ap(mm) Feed f(mm) Application Choice
Steel P15-P25 100-180 1.0-8.0 0.08-0.15 Good
Stainless M15-M25 90-160 1.0-4.0 0.08-0.13 Good
Cast iron K20-K30 100-190 1.0-8.0 0.08-0.15 OK
