LNMU03-63-22-8T High Feed Face Mill for LNMU 0303 Inserts 63mm diameter 8 Teeth 22mm bore

LNMU03-63-22-8T High Feed Face Mill for LNMU 0303 Inserts 63mm diameter 8 Teeth 22mm bore
Zoom  Zoom
Our Price:  £55.00(Exc. 20% VAT)(£66.00 Inc. VAT)

Model:  LNMU03-63-22-8T
Brand:  APT Tools

Shipped Weight:  750 g

Availability:

Item is on a long delivery or is discontinued

Item is on a long delivery or is discontinued

APT Tools

Tools for Indexable Inserts


LNMU03-63-22-8T High Feed Face Mill for LNMU 0303 Inserts 63mm diameter 8 Teeth 22mm bore.

63mm Diameter, 22mm Bore, 50mm High.

These cutters provide very high table feed at low cutting depth.

Suitable for high feed milling, slotting, ramping and helical interpolation.

Dimensions for LNMU03-63-22-8T (mm)
DiameterBoreHeightTeethInserts
6322508LNMU 0303



Ramping, Helical Interpolation and Plunging operating parameters (mm)
*For 63mm diameter cutters it's likely that the chips will be pushed back in to the material being cut when contouring, ramping or slot milling*
Cutter DiameterFace PlungingSide PlungingMax Ramping AngleMax Depth of CutHelical cuttingHelical cuttingHole Enlargement
DcPSα°ap maxMin Hole DiameterMax Hole Diameterae Max
63*0.33.50.31.011612459.5
