ELP2F-04020050R1 2mm Diameter 1mm Radius Lollipop Cutter 2 Flute Front and Back Profile End Mill 50mm Long 55HRC

ELP2F-04020050R1 2mm Diameter 1mm Radius Lollipop Cutter 2 Flute Front and Back Profile End Mill 50mm Long 55HRC
Zoom  Zoom
Our Price:  £6.00
List Price:  £9.00
Saving Of:  £3.00 (33%)
(Exc. 20% VAT)(£7.20 Inc. VAT)

Model:  ELP2F-04020050R1
Brand:  APT Carbide End Mills

Shipped Weight:  20 g

Availability:

In stock, immediate despatch

In stock, immediate despatch

APT Carbide End Mills

Carbide End Mills APT Brand


ELP2F-04020050R1 2mm Diameter 1mm Radius Lollipop Cutter 2 Flute Front and Back Profile End Mill 50mm Long 55HRC.

Ideal for Undercutting, 5 Axis Machining, Deburring, All Directional Spherical Cutting, Contouring, Machine Manifolds and Ports, Milling of Thin Walled Parts and other complex machining operations.

Suitable for materials up to 55HRC, performs well on Low to High Alloy Steel, Cast Iron, Copper, Mould Tool and Die Steel, 304 Stainless and 316 Stainless.

Dimensions for ELP2F-04020050R1 (mm)
Diameter (D) Shank Diameter (d) Neck Diameter (DN) Flute Length (L2) Reach (L1) Overall Length (L)
2 4 0.9 1.6 6 50



General cutting parameters recommended feed per tooth in mm (Fz).
Material Hardness HB Cutting Speed VC: m/min Fz mm Per Tooth Roughing Fz mm Per Tooth Finishing Application Choice
Non alloyed steel 0-0.45% C 150-250 160-280 (240) 0.040 0.030 Good
Low alloyed steel 250-300 180-240 (220) 0.040 0.030 Good
High alloyed steel 200 140-220 (180) 0.034 0.030 Good
Corrosion resistant steel 200 100-200 (140) 0.032 0.030 Good
Stainless - Ferritic 200 120-200 (160) 0.022 0.030 Good
Stainless - Austenitic 180 100-180 (140) 0.030 0.030 Good
Stainless - Martensitic 330 70-140 (120) 0.030 0.030 Good
Grey cast iron 180-260 180-260 (220) 0.040 0.030 Good
Malleable / Tempered iron 130-230 160-220 (190) 0.022 0.030 Good
Aluminium Alloys 130-230 200-500 (350) 0.050 0.030 OK
Copper, Bronze, Brass 130-230 150-400 (250) 0.040 0.030 Good
Iron Based Hi-temp Alloys 200-280 HB 200-280 30-50 (40) 0.021 0.018 OK
Nickel or Cobalt Based 250 HB 250 15-30 (20) 0.021 0.018 OK
Nickel or Cobalt Based 30-58 HRC - 15-25 (20) 0.021 0.018 OK
Titanium Alloys 350 60-120 (90) 0.024 0.020 Good
Hardened Steel 40-50HRC 100-180 (140) 0.026 0.024 OK
Recommended Coolant.
Material Hardness HB Flood Coolant Air Coolant Min Mist Coolant
Non alloyed steel 0-0.45% C 150-250 OK Good Good
Low alloyed steel 250-300 OK Good Good
High alloyed steel 200 OK Good Good
Corrosion resistant steel 200 OK Good Good
Stainless - Ferritic 200 Good OK OK
Stainless - Austenitic 180 Good OK OK
Stainless - Martensitic 330 Good OK OK
Grey cast iron 180-260 OK Good No
Malleable / Tempered iron 130-230 OK Good No
Aluminium Alloys 130-230 Good No OK
Copper, Bronze, Brass 130-230 Good No OK
Iron Based Hi-temp Alloys 200-280 HB 200-280 Good No No
Nickel or Cobalt Based 250 HB 250 Good No No
Nickel or Cobalt Based 30-58 HRC - Good No No
Titanium Alloys 350 Good No No
Hardened Steel 40-50HRC OK Good OK
