ELP2F-06060050R3 6mm Diameter 3mm Radius Lollipop Cutter 2 Flute Front and Back Profile End Mill 50mm Long 55HRC

ELP2F-06060050R3 6mm Diameter 3mm Radius Lollipop Cutter 2 Flute Front and Back Profile End Mill 50mm Long 55HRC
Zoom  Zoom
Our Price:  £10.00
List Price:  £15.00
Saving Of:  £5.00 (33%)
(Exc. 20% VAT)(£12.00 Inc. VAT)

Model:  ELP2F-06060050R3
Brand:  APT Carbide End Mills

Shipped Weight:  40 g

Availability:

In stock, immediate despatch

In stock, immediate despatch

APT Carbide End Mills

Carbide End Mills APT Brand


ELP2F-06060050R3, 6mm Diameter 3mm Radius Lollipop Cutter 2 Flute Front and Back Profile End Mill 50mm Long 55HRC.

Ideal for Undercutting, 5 Axis Machining, Deburring, All Directional Spherical Cutting, Contouring, Machine Manifolds and Ports, Milling of Thin Walled Parts and other complex machining operations.

Suitable for materials up to 55HRC, performs well on Low to High Alloy Steel, Cast Iron, Copper, Mould Tool and Die Steel, 304 Stainless and 316 Stainless.

Dimensions for ELP2F-06060050R3 (mm)
Diameter (D)Shank Diameter (d)Neck Diameter (DN)Flute Length (L2)Reach (L1)Overall Length (L)
662.94.81650



General cutting parameters recommended feed per tooth in mm (Fz) use appropriate cooling.
MaterialHardness HBCutting Speed VC: m/minFz mm Per Tooth RoughingFz mm Per Tooth FinishingApplication Choice
Non alloyed steel 0-0.45% C150-250160-280 (240)0.1200.090Good
Low alloyed steel250-300180-240 (220)0.1200.090Good
High alloyed steel200140-220 (180)0.1060.090Good
Corrosion resistant steel200100-200 (140)0.0980.090Good
Stainless - Ferritic200120-200 (160)0.1060.090Good
Stainless - Austenitic180100-180 (140)0.0900.090Good
Stainless - Martensitic33070-140 (120)0.0900.090Good
Grey cast iron180-260180-260 (220)0.1200.090Good
Malleable / Tempered iron130-230160-220 (190)0.1060.090Good
Aluminium Alloys130-230200-500 (350)0.1500.090OK
Copper, Bronze, Brass130-230150-400 (250)0.1200.090Good
Iron Based Hi-temp Alloys 200-280 HB200-28030-50 (40)0.0600.048OK
Nickel or Cobalt Based 250 HB25015-30 (20)0.0600.048OK
Nickel or Cobalt Based 30-58 HRC-15-25 (20)0.0600.048OK
Titanium Alloys35060-120 (90)0.0720.060Good
Hardened Steel40-50HRC100-180 (140)0.0780.075OK
Recommended Coolant.
MaterialHardness HBFlood CoolantAir CoolantMin Mist Coolant
Non alloyed steel 0-0.45% C150-250OKGoodGood
Low alloyed steel250-300OKGoodGood
High alloyed steel200OKGoodGood
Corrosion resistant steel200OKGoodGood
Stainless - Ferritic200GoodOKOK
Stainless - Austenitic180GoodOKOK
Stainless - Martensitic330GoodOKOK
Grey cast iron180-260OKGoodNo
Malleable / Tempered iron130-230OKGoodNo
Aluminium Alloys130-230GoodNoOK
Copper, Bronze, Brass130-230GoodNoOK
Iron Based Hi-temp Alloys 200-280 HB200-280GoodNoNo
Nickel or Cobalt Based 250 HB250GoodNoNo
Nickel or Cobalt Based 30-58 HRC-GoodNoNo
Titanium Alloys350GoodNoNo
Hardened Steel40-50HRCOKGoodOK
