SEKT 1204 AFER NK135 Carbide Inserts for Milling PVD Coated for General Use APT

SEKT 1204 AFER NK135 Carbide Inserts for Milling PVD Coated for General Use APT
Zoom  Zoom
Our Price:  £6.46
List Price:  £9.69
Saving Of:  £3.23 (33%)
(Exc. 20% VAT)(£7.75 Inc. VAT)

Model:  SEKT1204AFERNK135
Brand:  APT Carbide

Shipped Weight:  8 g

Availability:

Only 70 left in stock - order soon

Only 70 left in stock - order soon

APT Carbide

Carbide Inserts APT Brand utilising modern Base Grades, MT-CVD & PVD Coatings and proven Chip Geometries


Carbide Inserts for Milling PVD Coated Grade NK135 (P35–M35–S15 + PVD TiN (Ti–Al–Si)N Coating) Main application – Carbon & Alloy Steel, extended application – Stainless Steel & Hi–Temp Alloy

Geometry for Alloy Steel, Stainless & Hi–Temp Alloy

Dimensions for SEKT 1204 AFER NK135 (mm)
Length Inscribed Circle or Width Thickness Hole Dia Corner Facet Corner Radius Side Clearance
12.7 12.7

4.76

5.5 45°x1.8 0.4 20°
General Cutting parameters
Material Hardness HB Cutting Speed VC: m/min Depth of Cut ap(mm) Feed f(mm) Application Choice
Non alloyed steel 0-0.45% C 150-250 100-220 2.0-6.0 0.15-0.30 Good
Low alloyed steel 250-300 100-220 2.0-6.0 0.15-0.30 Good
High alloyed steel 200 100-220 2.0-6.0 0.15-0.30 Good
Corrosion resistant steel 200 100-220 2.0-6.0 0.15-0.30 Good
Stainless - Ferritic 200 80-160 2.0-3.0 0.15-0.25 Good
Stainless - Austenitic 180 80-160 2.0-3.0 0.15-0.25 Good
Stainless - Duplex 230-260 80-160 2.0-3.0 0.15-0.25 Good
Stainless - Martensitic 330 80-160 2.0-3.0 0.15-0.25 Good
Iron Based Hi-temp Alloys 200-280 30-70 1.0-2.0 0.15-0.20 OK
Nickel or Cobalt Based 30-58 HRC - 30-70 1.0-2.0 0.15-0.20 OK
Nickel or Cobalt Based 250 HB 250 30-70 1.0-2.0 0.15-0.20 OK
Pure Titanium - 30-70 1.0-2.0 0.15-0.20 OK
Titanium  Alpha + Beta Alloys - 30-70 1.0-2.0 0.15-0.20 OK
